TPQA-1300 paper slitting rewinding machine

TPQA-130 paper slitting rewinding machine-TPQA-1300 paper slitting rewinding machine

Suitable materials:70-200g paper
Web width: 800-1100-1400mm
Shafted unwind, Max. diameter 1400mm
Stack type: Side conveyor
PLC and HMI design
This machine is specially designed for cutting and wrapping A4 or A3 size paper. Equipped with conveyor stacker, you can get stack of A4 or A3 paper directly, then reams will be delivered to the packing machine to pack it.

√ one-year guarantee √ 24 hours technology support √ engineer available for installation

Read More
TPQL-1300-1600-1800-2000 heavy duty slitting machine

TPQL-1300-1600-1800-2000 heavy duty slitting machine

uitable materials: 30-450g paper(Main), Sticky label, Various laminates, thick film, Nonwoven, etc.
Web width: 1300-1600-1800-2000-2300-2600-2800-3000mm
Max. rewind diameter: 1500mm
Max. speed ≤500m/min
This jumbo paper roll-to-roll slitter rewinder is suitable for slitting and rewinding large wide jumbo rolls, like various papers, adhesive stickers, or some laminates into narrow-width rolls. We specially designed it with a large unwind and rewind diameter(1500mm) to fulfill the customers’ requirements who want to get big diameter finished rolls.

√ one-year guarantee √ 24 hours technology support √ engineer available for installation

Read More
TPQD-1300-1600-1800 high speed slitter rewinder

TPQD-1300-1600-1800 high speed slitter rewinder

Suitable materials: 30-450g paper(Main), Sticky label, Various laminates, thick film, Nonwoven, etc.
Web width: 1300-1600-1800-2000-2600mm
Max. rewind diameter: 1500mm
Max. speed 600-800m/min
This machine is suitable for rewinding and slitting large jumbo rolls, like various papers, adhesive stickers, or some laminates into the desired diameter roll with a smooth edge. We specially designed it with a large rewind diameter(1500mm) and super high speed(600-800m/min) to fulfill the customers’ requirements who want to get big diameter finished rolls efficiently.

√ one-year guarantee √ 24 hours technology support √ engineer available for installation

Read More
TPQA-1300 paper slitting rewinding machine

TPQA-130 paper slitting rewinding machine-TPQA-1300 paper slitting rewinding machine

Suitable materials:70-200g paper
Web width: 800-1100-1400mm
Shafted unwind, Max. diameter 1400mm
Stack type: Side conveyor
PLC and HMI design
This machine is specially designed for cutting and wrapping A4 or A3 size paper. Equipped with conveyor stacker, you can get stack of A4 or A3 paper directly, then reams will be delivered to the packing machine to pack it.

√ one-year guarantee √ 24 hours technology support √ engineer available for installation
Get A Inqury

Video

Specifications

Features

Photo Show









Model TPQA-1300W TPQA-1600W TPQA-1800W TPQA-2000W
Max. web width(mm) 1300 1600 1800 2000
Max. unwind diameter(mm) Φ1400
Unwind stand Shaft-less auto loading & floating type
Unwind tension control Magnetic powder brake with PLC control
Inner core diameter(mm) 76mm(3”) and 152mm(6”) step chuck
Web guiding system Ultrasonic sensor
Slitting techniques Rotary shear knife and Razor blade cutting in air
Trim disposal Trim suction fan 2.2kw
Max. rewinding diameter(mm) Φ1000(Φ1200 can be customized)
Rewinding tension control Two rewinding servo motors with PLC control
Inner core diameter(mm) 76mm(3”)
Min. rewinding web width(mm) 30 40 60 60
Mechanical speed(m/min) ≤400
Cutting thickness For paper:30-300g, For film: 30-300μm (according to the materials)
Cutting accuracy(mm) ±0.15
Main Motor Power(kw) 7.5 7.5 11 11
Rewind motor(kw) 7.5*2 7.5*2 11*2 11*2
Total power(kw) 27 27 37 37
Power supply 380V 50HZ 3phases(other voltage can be customized)
Air supply 0.6-0.8 Mpa, 0.8m3/Min
Net weight(kg) 4500 5200 5800 6000
Overall Dimension(mm) 3700*3100*2100 3700*3400*2100 3700*3600*2100 3700*3800*2100




Features:

1. Three individual servo motors’ synchronous control provides accurate web tension which is calculated by PLC.

2. Siemens PLC control system with touch screen brings much convenience for the operator, it has multi-functions, like meter reached auto stop, tension auto control, and so on.

3. Shaftless unwind with hydraulic auto loading for heavy jumbo rolls and web guiding system to detect the web position.

4. Automatic rolls unloading structure for rewinding shafts: mechanical arm moving on the linear guide rail to unload the shaft.

5. Be equipped with rotary shear slitting knives and a high-power trim edge suction fan.



Standard configuration:

Unwinding system

  1. shaft-less unwinder, 3” and 6” use in common.
  2. Hydraulic lifter for heavy jumbo roll, Max diameter 1400mm and Max weight 2t.
  3. The left and right arms are controlled by hydraulic and can be moved separately.
  4. Tension control by magnetic powder brake
  5. Web-guiding system: an ultrasonic sensor to detect the web position

Transmission and driven system

  1. Main servo motor with frequency converter.
  2. Synchronous belt transmission.
  3. Pneumatic nip rubber roller.

Slitting section

  1. Circular knives 10 pcs
  2. Trim disposal: 3kw trim suction fan

Rewinding section

  1. Servo motor 2pcs for rewinding.
  2. Auto unloading system(Click here to see video): mechanical arm moving on the linear guide rail to unload the shaft with finished rolls
  3. 3-inch air shafts*2, the Max. Diameter is Φ1000
  4. Pneumatic lay-on roller guarantees full contact between lay-on roller and slit roll

Electric section

  1. LCD colorful touch-screen and PLC (Siemens).
  2. Unwinding tension control and rewinding tension adjustment.
  3. Speed adjustment function.



null
TPQL-1300-1600-1800-2000 heavy duty slitting machine

TPQL-1300-1600-1800-2000 heavy duty slitting machine

uitable materials: 30-450g paper(Main), Sticky label, Various laminates, thick film, Nonwoven, etc.
Web width: 1300-1600-1800-2000-2300-2600-2800-3000mm
Max. rewind diameter: 1500mm
Max. speed ≤500m/min
This jumbo paper roll-to-roll slitter rewinder is suitable for slitting and rewinding large wide jumbo rolls, like various papers, adhesive stickers, or some laminates into narrow-width rolls. We specially designed it with a large unwind and rewind diameter(1500mm) to fulfill the customers’ requirements who want to get big diameter finished rolls.

√ one-year guarantee √ 24 hours technology support √ engineer available for installation
Get A Inqury

Video

Specifications

Features

Photo Show









Model TPQL-1300 TPQL-1600 TPQL-1800 TPQL-2000 TPQL-2600 TPQL-3000
Max. web width(mm) 1300 1600 1800 2000 2600 3000
Max. unwind Dia(mm) Φ1800
Unwinding stand Heavy duty shaft-less auto loading & floating type
Unwinding tension control Pneumatic brake with PLC control
Inner core diameter(mm) 76mm(3”) & 152mm(6”) step chuck
Web guiding system Ultrasonic sensor
Slitting techniques Rotary shear knife
Trim disposal Trim suction fan 5.5kw
Max. rewind Dia(mm) Φ1500
Rewinding tension control Two rewinding servo motors
Inner core diameter(mm) 76mm(3”)
Min.slitting width(mm) 50 50 50 60 80 100
Mechanical speed(m/min) ≤500
Cutting thickness For paper:50-450g (according to the materials)
Cutting accuracy(mm) ±0.15
Main motor(kw) 18.5 18.5 18.5 18.5 22 22
Rewind motor(kw) 15*2 15*2 15*2 15*2 18.5*2 18.5*2
Total power(kw) 55 55 57 58 65 67
Power supply 380V 50HZ 3phases(other voltage can be customized)
Air supply 0.6-0.8 Mpa, 0.8m3/Min
Weight(kg) 13000 14500 15000 16000 20000 22000
Overall Dimension(mm) 8100*4400*2300 8100*4600*2300 8100*4800*2300 8100*5000*2300 8100*5600*2300

8100*6000*2300




Features:

1.  Three individual servo motors with gear reducer synchronous control provides accurate web tension which is calculated by PLC.

2. Siemens PLC control system with touch screen brings much convenience for the operator, it has multi-functions, like meter reached auto stop, tension auto control, and so on.

3. Heavy-duty shaftless unwind with hydraulic auto loading for heavy jumbo rolls and web guiding system to detect the web position.

4. Automatic rolls unloading structure: hydraulic control to unload the shaft with heavy finished rolls.

5. Be equipped with durable SKD rotary shear slitting knives and a high-power trim edge suction fan.

6. Motor control web auto handling from unwind to traction roller can largely improve the efficiency of the operator.


Standard configuration:

Heavy-duty unwind stand

1. Floating type shaft-less unwind stand, 3”and 6” step chuck.

2. Hydraulic lifter for heavy jumbo roll, Max diameter 1800mm and Max weight 3600kg.

3. Left and right arm is controlled by hydraulic, and can be moved separately.

4. Web adjustment roller ensures the web tension balance from left to right..

5. Tension is calculated by PLC and controlled by Italy RE pneumatic brake automatically.

6. Web-guiding system: ultrasonic sensor(Pausource) to detect the web position.

7. Constant closed-loop tension control system(optional): the tension is sensed by load cell sensor and compared to the set tension.

Traction section

1. Web dancer roller for long path tension control

2. Motor control web auto handling from unwind to traction roller.

3. Banana roller to spread the web.

4. Servo motor is connected to the double traction rubber rollers.

5. Pneumatic nip rubber roller, the pressure of nip can be adjusted: providing perfect tension isolation.

Slitting section

1. Rotary shear knives(SKD materials) 10 sets.

2. Cantilever upper knife shaft.

3. Upper knife up/down adjustment and left/right fine-adjustment are controlled pneumatically.

3. Pneumatic bottom knife shaft is convenient to unload or load the bottom rotary knives.

4. Trim disposal: 3 kw trim suction fan.

Rewinding section

1. The left and right rewind structure, 2 pcs 3” strengthened airshaft center winding with shaft support, the Max. rewind diameter 1500mm.

2. Pneumatic clamp for rewind shaft.

3. Servo motor(2 sets) drive system with gear reducer provides the accurate winding tension control.

4. Automatic rolls unloading structure: hydraulic control to unload the shaft with heavy finished rolls.

5. Pneumatic rewind shaft laying on big metal cylinder guarantees full contact between big metal roller and slit roll, the lay-on pressure can be adjusted.

PLC and touch screen

1. Colorful 10” touch-screen and PLC (Siemens).

2. Chinese, English and Russian language(optional) on touch screen

3. Automatic tension& diameter calculate and control: Set taper and initial tension on touch screen for your materials, PLC will detect current tension and current diameter automatically and accurately.

4. Meter reached auto alarm and stop function.

5. Unwind Set diameter reached auto alarm and stop function.

6. One button auto speed up function: Press one button, machine will speed up to your set speed smoothly and automatically.

7. Rewind shaft forward and backward function.

8. Problem diagnosis function on touch screen, if any problems occur, you can check I/O page to find it.
